RADIAL ARM - 5 SPEED BENCH DRILL PRESS

Original price $760.00 - Original price $760.00
Original price
$760.00
$760.00 - $760.00
Current price $760.00

Palmgren’s radial arm drill presses have an extended reach, tilting drill head that is ideal for large or odd-shaped work pieces.  The table tilts 45° left or right allowing easy machining of holes at almost any angle.


  • Durable cast iron head, table & base
  • Spindle supported by high quality ball bearings
  • Rack and pinion table raiser
  • Table tilts 45° right & left and swivels 360° around the column
  • 1/2" through table & base slots for easy mounting and clamping of workpiece
  • Front mounted safety, paddle on/off switch
  • Drill chuck & key
SPECIFICATION DESCRIPTION
Model 80341
Swing 9 to 33 in
Motor HP 1/2 HP
Voltage 115
Amps 4.8 A
Capacity Cast Iron 5/8 in
Spindle Speeds 5
RPM 575-3520
Spindle Taper MT2
Spindle Travel 3- 5/32 in
Spindle to Table 15 in
Table Work Surface 8-7/8 x 9 in
Table Slots 1/2 in
Height 37
Width 10 in
Depth 33 in
