When it comes to selecting a complete TIG welding package, the Crossfire ECOWAVE 200 AC/DC TIG Welder is the ideal welder's choice. The inverter based design offers the ultimate in arc performance. Outputs include Stick, DC TIG and AC TIG, required
for superior aluminum welding. The machine is packed with features desirable for TIG welding including pulse control and a wide range of pre-weld and post-weld options. with remote contactor control and infinite amperage range from 10 - 200 amps.
The ECOWAVE 200 comes complete and ready to tackle your most demanding TIG welding applications.

Features and Benefits

  • Portable digital AC/DC machine, high efficient inverter technology
  • Perfect welding quality on heat-sensitive material and aluminum
  • Controlled AC wave, including balance, AC frequency
  • Fully controlled pulse wave, including pulse duty cycle, base current and high speed pulse frequency
  • HF and lift arc ignition, outstanding arc starting performance
  • PFC module, reduce harmonic wave input, improves power efficiency


  • 6 ft. power input cord and 230V plug
  • 115V power adapter
  • 10' Ground Cable with clamp
  • Infinite amperage control
  • Flow Gauge CGA580 with 10' gas hose
  • Remote Foot Control Kit
  • WP26 Welding torch with 16ft lead, includes remote control
  • Consumable Starter Kit

Stick/TIG Parameter Chart

Rated Input

115/230 Volts
Single Phase
50/60 Hz

Part Number


Rated Output


10 - 120 @ 115V
35% Duty Cycle @ 120A

10 - 200 @ 230V
20% Duty Cycle @ 200A

10 - 80A @ 115V
35% Duty Cycle @ 80A

10 - 160 @ 230V
20% Duty Cycle @ 160A



H. 19.2” (488 mm) W. 9.5” (243 mm) L. 16” (408 mm)


Net: 32 lb (14.5 kg)
