DynaFlux ProCool 2 Welding Torch Water Cooler

500 Amp Compact Welding Torch Water Cooler

A small footprint, high efficiency, made in the USA MIG/TIG torch water cooler. This unit is great for welders that want to push the limits of their TIG welder, but don't have the floor space for a bulky water cooler. This small unit fits with little room to spare on the bottom shelf of most common welder carts, and can run a 350 amp #18 TIG torch at max capacity with 100% duty cycle on AC cycle. Plugs into a standard 115V North American wall outlet.

Cooling Compatibility:

• MIG welding up to 500 amps
• TIG welding up to 500 amps
• Resistance welders up to 60KVA
• Plasma cutters up to 200 amps

Features:

• Plastic water tank eliminates coolant contamination due to electrolysis or chemical reactions.
• All units are plumbed with copper tubing and reinforced hose.
• New extended life pump features a direct drive power system reducing maintenance and vibration.
• No external plumbing is required because of closed loop water system.
• Self priming pump
• Easy change pump
• Strong rigid construction designed to support power unit.
• Compact design

• Made in USA

Specifications:

• Factory set at 50 psi adjustable to 80 psi
• 3 gallon reservoir
• 115 or 230 VAC / 1 ph-50/60Hz
• 5.6 / 2.8 amp:60 Hz
• 12,000 BTU
• Dimensions: 18″L x 14″W x 9″H
• Net weight: 37 lbs / 17 kg

• Standard 5/8" x 18 LH threads for North American standard TIG torches

Options Available:

• Rotary GEAR Pump W/ built in by-pass to tank and rebuildable pump
• Rotary VANE Pump

CLICK HERE FOR OFFICIAL SPEC SHEET

This is not a common stock item. Please allow an extra 1-2 week lead time
